​High-Barrier Aluminum Foil Roll Film
  • ​High-Barrier Aluminum Foil Roll Film
  • ​High-Barrier Aluminum Foil Roll Film
  • ​High-Barrier Aluminum Foil Roll Film
  • ​High-Barrier Aluminum Foil Roll Film
  • ​High-Barrier Aluminum Foil Roll Film
​High-Barrier Aluminum Foil Roll Film

​High-Barrier Aluminum Foil Roll Film

Place of Origin Guangdong,China
Brand Name Bright Pack
Certification patent for invention、BRC、GRS
Model Number B010
Product Details
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Highlight:

Aluminum Foil Roll Film

,

High Barrier Aluminum Foil Roll Film

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
$3-3.5/kg
Packaging Details
Export special carton packaging and plate
Delivery Time
11-13work days
Payment Terms
T/T,Western Union
Supply Ability
200000pcs/day
Product Description

Product Attributes & Specifications​

​Category​ ​Attribute​ ​Specification​ ​Notes / Test Standards​
​Material Structure​ Layer Composition PET (Outer) + Aluminum Foil (Barrier) + PE (Sealing) 3–5 layers; customizable adhesion coatings
1
3

Total Thickness ​70–200 μm​ (customizable)
- PET: 12–30 μm
- Aluminum: 6–9 μm
- PE: 50–150 μm		 Adjustable per application
1
3
​Mechanical Properties Puncture Resistance ​**≥35 N**​ ASTM D7513/D6241; industrial-grade durability
1
4

Tensile Strength (MD/TD) PET: ≥150/120 MPa
PE: ≥20/18 MPa		 Ensures structural integrity during processing
1
3

Elongation at Break 400–600% Maintains flexibility for high-speed packaging
1
​Barrier Performance​ Water Vapor Transmission (WVTR) ​​≤0.02 g/m²/day​ ASTM E96 (38°C, 90% RH); blocks 99% moisture
3
9

Oxygen Transmission (OTR) ​​≤0.1 cm³/m²/day​ ASTM D3985 (23°C, 0% RH); near-total O₂ barrier
3
9

Light Blocking Blocks 99% UV/visible light Critical for light-sensitive products (e.g., vitamins)
1
5
​Thermal Properties​ Heat Sealing Range ​140–200°C​ Compatible with PP/PE substrates; PE-sealant layer
3
6

Temperature Resistance ​Storage: -40°C to +120°C
​Operational: -30°C to +70°C		 Industrial-grade thermal stability
3
4
​Functional Features​ Seal Strength 5–10 N/15mm (peelable or permanent) Customizable for easy-open/lidding
2
3

Printability Up to 8-color flexographic/rotogravure printing Reverse printing on PET layer; smudge-resistant
1
5

Surface Finish Glossy, matte, metallic; optional transparent windows Aesthetic and functional customization
5
6
​Applications​ Primary Use Cases Coffee, nuts, dairy, pharmaceuticals, electronics, cosmetics Extends shelf life by 30–50%
1
5
9
​Roll Specifications​ Width 150–1200 mm (slit to order)
1
3

Length 500–6000 meters per roll
1
2

Core Diameter 76 mm / 152 mm (standard); customizable Core-less or cored options
3
5
​Certifications​ Compliance FDA 21 CFR, EU 10/2011, ISO 22000, RoHS, REACH Global food/pharma safety standards
1
2
3

Sustainability Recyclable aluminum; eco-friendly PE v
