PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

Place of Origin	Guangdong,China
Brand Name	Bright Pack
Certification	patent for invention、BRC、GRS
Model Number	B010

Product Details

Customization:

Support

Colour:

Up To 10 Colour Or No Printed

Odor Proof:

Yes

Custom Order:

YES.

Colors:

CMYK/Pantone

Sample:

Free

Puncture Resistant:

Yes

Packaging Type:

Bulk Pack

Quantity Per Pack:

100

Recyclable:

Yes

Quantity:

Pack Of 100 Bags

Bag Type:

Three Side Seal Stand Up Bag

Bpa Free:

Yes

Color:

Transparent

Height:

115 MM

Highlight:

Chemical Stability Disinfectant Film Roll

Lightproof Disinfectant Film Roll

Transparent Disinfectant Film Roll

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

$3-3.5/kg

Packaging Details

Export special carton packaging and plate

Delivery Time

11-13work days

Payment Terms

T/T,Western Union

Supply Ability

200000pcs/day

Product Description

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

Product Attributes

Attribute	Description
Material Structure	Trilayer composite: PET outer (mechanical strength/UV blocking), Aluminum middle (oxygen/moisture barrier), PE inner (heat-sealable & chemical-resistant)
Primary Function	Ensures chemical stability of ClO₂ disinfectant by blocking light/oxygen/moisture; prevents gas leakage and decomposition
Barrier Technology	Aluminum foil (7-12 µm) reduces OTR to ≤0.05 cm³/m²/day (ASTM F1249) + PET layer blocks 99% UV light to inhibit ClO₂ photolysis
Seal Integrity	PE inner layer enables strong heat seals (≥25 N/15mm); compatible with ultrasonic sealing to avoid ClO₂ thermal degradation (>80°C)
Surface Treatment	Anti-static coating (≤10⁹ Ω/sq) prevents dust adsorption during high-speed filling; lightproof black/amber PET variants available
Chemical Stability	Neutral pH (6.5-7.5) and inert layers prevent reactions with ClO₂; maintains ≥95% active ingredient efficacy for 12 months
Certifications	Complies with FDA 21 CFR, ISO 22000 for indirect food contact; EPA-registered for disinfectant packaging
Sustainability	Recyclable PET/AL/PE structure; biodegradable PLA/PE alternatives available (EN13432 certified)

Product Specifications

Parameter	Specification	Test Standard
Thickness	80-200 µm (customizable; 120 µm standard for heavy-duty use)	ISO 4593
OTR (Oxygen Transmission Rate)	≤0.05 cm³/m²/day	ASTM F1249
WVTR (Water Vapor Transmission Rate)	≤0.5 g/m²/day	ASTM D3985
Light Transmittance	<0.5% (UV-Vis range, 200-400nm)	ASTM D1003
Puncture Resistance	≥35 N (protects against sharp disinfectant crystals)	ASTM D7192
Seal Strength	≥25 N/15mm (heat seal), ≥20 N/15mm (ultrasonic cold seal)	ASTM F88
Thermal Stability	-40°C to 100°C (withstands freezing/boiling; ClO₂ decomposition threshold: >80°C)	ASTM D882
Surface Resistance	10⁸-10¹¹ Ω/sq (anti-static)	ASTM D257
Roll Dimensions	Width: 200-1,200 mm Length: 1,000-10,000 m Core ID: 76 mm (3") or 152 mm (6")	N/A
MOQ & Logistics	MOQ: 500 kg Lead Time: 15-25 days Packaging: Moisture-proof wooden pallets	N/A

PET/AL/PE ClO₂ Disinfectant Film Roll close-up showing material layers

Industrial roll of ClO₂ Disinfectant Film on production line

Sealed package sample using the ClO₂ Disinfectant Film
