PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
  • PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
  • PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
  • PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
  • PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
  • PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability
PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

PET/AL/PE ClO₂ Disinfectant Film Roll 0.05 OTR Barrier & Lightproof For Chemical Stability

Place of Origin Guangdong,China
Brand Name Bright Pack
Certification patent for invention、BRC、GRS
Model Number B010
Product Details
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Highlight:

Chemical Stability Disinfectant Film Roll

,

Lightproof Disinfectant Film Roll

,

Transparent Disinfectant Film Roll

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
$3-3.5/kg
Packaging Details
Export special carton packaging and plate
Delivery Time
11-13work days
Payment Terms
T/T,Western Union
Supply Ability
200000pcs/day
Product Description

​Product Attributes​

​Attribute​ ​Description​
​Material Structure​ Trilayer composite: ​PET outer​ (mechanical strength/UV blocking), ​Aluminum middle​ (oxygen/moisture barrier), ​PE inner​ (heat-sealable & chemical-resistant)
​Primary Function​ Ensures chemical stability of ClO₂ disinfectant by blocking light/oxygen/moisture; prevents gas leakage and decomposition
1
6
​Barrier Technology​ Aluminum foil (7–12 µm) reduces OTR to ​​≤0.05 cm³/m²/day​ (ASTM F1249) + PET layer blocks 99% UV light to inhibit ClO₂ photolysis
1
6
​Seal Integrity​ PE inner layer enables strong heat seals (≥25 N/15mm); compatible with ultrasonic sealing to avoid ClO₂ thermal degradation (>80°C)
4
9
​Surface Treatment​ Anti-static coating (≤10⁹ Ω/sq) prevents dust adsorption during high-speed filling; lightproof black/amber PET variants available
1
5
​Chemical Stability​ Neutral pH (6.5–7.5) and inert layers prevent reactions with ClO₂; maintains ≥95% active ingredient efficacy for 12 months
11
13
​Certifications​ Complies with ​FDA 21 CFR, ​ISO 22000​ for indirect food contact; EPA-registered for disinfectant packaging
8
10
​Sustainability​ Recyclable PET/AL/PE structure; biodegradable PLA/PE alternatives available (EN13432 certified)
6
7

​Product Specifications

​Parameter​ ​Specification​ ​Test Standard​
​Thickness​ 80–200 µm (customizable; 120 µm standard for heavy-duty use) ISO 4593
​OTR (Oxygen Transmission Rate)​​ ≤0.05 cm³/m²/day ASTM F1249
​WVTR (Water Vapor Transmission Rate)​​ ≤0.5 g/m²/day ASTM D3985
​Light Transmittance​ <0.5% (UV-Vis range, 200–400nm) ASTM D1003
​Puncture Resistance​ ≥35 N (protects against sharp disinfectant crystals) ASTM D7192
​Seal Strength​ ≥25 N/15mm (heat seal), ≥20 N/15mm (ultrasonic cold seal) ASTM F88
​Thermal Stability​ -40°C to 100°C (withstands freezing/boiling; ClO₂ decomposition threshold: >80°C)
4
13
 ASTM D882
​Surface Resistance​ 10⁸–10¹¹ Ω/sq (anti-static)
1
 ASTM D257
​Roll Dimensions​ - ​Width: 200–1,200 mm
- ​Length: 1,000–10,000 m
- ​Core ID: 76 mm (3") or 152 mm (6")		 N/A
​MOQ & Logistics​ - ​MOQ: 500 kg
- ​Lead Time: 15–25 days
- ​Packaging: Moisture-proof wooden pallets
