Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
  • Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
  • Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
  • Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
  • Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
  • Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection
Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection

Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection

Place of Origin Guangdong,China
Brand Name Bright Pack
Certification patent for invention、BRC、GRS
Model Number B010
Product Details
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
￥0.02-0.11/pcs
Packaging Details
Export special carton packaging and plate
Delivery Time
11-13work days
Payment Terms
T/T,Western Union
Supply Ability
200000pcs/day
Product Description

Product Attributes & Specifications Table for "Anti-Static Aluminum Foil Roll Film | 0.006g/m²·24h WVTR & ESD Protection"

​Attribute ​Specifications ​Reference
​Material Structure Multi-layer composite: Aluminum foil (7–30µm) laminated with anti-static PET/PE layers. Anti-static coating (surface resistance: 10⁶–10¹¹ Ω/sq) for ESD protection.
1
4
​Barrier Performance - Water Vapor Transmission Rate (WVTR): ≤0.006 g/m²·24h (38°C, 90% RH)
- Oxygen Transmission Rate (OTR): ≤0.05 cc/m²·day (25°C, 0% RH).
3
4
​ESD Protection Conductive/static-dissipative layers compliant with ANSI/ESD S20.20 and IEC 61340-5-1 standards. Surface resistance ≤10¹¹ Ω/sq.
8
9
​Thickness 80–200 microns (adjustable based on application requirements). Aluminum layer customizable (7µm for lightweight, 30µm for heavy-duty).
1
4
​Width & Length - Standard width: 200–1,200mm
- Roll length: 500–5,000 meters (core diameter: 76mm or 152mm).
1
5
​Surface Finish Matte or gloss finish. Optional embossed patterns for enhanced grip and aesthetics.
3
5
​Thermal Resistance Stable performance from -40°C to 150°C. Suitable for heat-sealing and sterilization processes.
1
4
​Certifications FDA 21 CFR 177.1390 (food contact), ISO9001, REACH, and RoHS compliance. ESD certification per IEC 61340.
1
8
​Applications - ESD-sensitive electronics (PCBs, ICs)
- Pharmaceutical blister packaging
- Military-grade equipment
- High-moisture barrier food packaging.
1
8
9
​Sustainability Recyclable aluminum layer. PE/PET components compatible with industrial recycling streams.
3
4
​Additional Features - Printability: Compatible with flexographic and gravure printing for branding.
- Customizable adhesive backing for lamination.
5
9
