Place of Origin | Guangdong,China |
Brand Name | Bright Pack |
Certification | patent for invention、BRC、GRS |
Model Number | B010 |
Attribute | Description |
---|---|
Material | Outer layer: Premium BOPET (biaxially oriented polyester, 25–40µm, high-gloss finish); Inner layer: Food-grade PE/CPP (50–80µm, heat-sealable, moisture/oxygen barrier); Glossy gold trim: Metallic foil lamination (5–10µm) |
Structure | 3-layer laminate (BOPET + Adhesive + PE/CPP) with integrated gold foil trim and embossed branding |
Design Features | - Glossy gold foil accents (edges/seams) - Custom embossed/debossed logos/text (depth: 0.2–0.5mm) |
Printing | High-resolution rotogravure printing; Pantone metallic gold/silver inks; CMYK full-color support |
Seal & Closure | Heat-sealed top with tear notch; optional zip-lock or degassing valve (±2psi) |
Certifications | FDA 21 CFR 177.1630, EU 10/2011 food-safe, RoHS compliant, ISO 9001 |
Capacity | 8oz (227g) to 2lbs (0.9kg); ideal for premium retail coffee packaging |
Dimensions | - Width: 4–10 inches (10–25cm) - Height: 6–16 inches (15–40cm) - Gusset: 1–2.5 inches (2.5–6.3cm) |
Packaging Format | Flat-packed with protective interleaving; 50–150 pcs/box (retail-ready display) |
Parameter | Details |
---|---|
Material Thickness | - BOPET outer: 25–40µm - Gold foil trim: 5–10µm - PE/CPP inner: 50–80µm - Total thickness: 80–130µm |
Embossing Precision | Logo/text depth: 0.2–0.5mm (resolution ≥200 DPI for intricate designs) |
Print Quality | 175–250 LPI rotogravure; metallic ink adhesion ≥4B (ASTM D3359 cross-cut test) |
Seal Strength | Heat seal: ≥3.8N/15mm (ASTM F88); gold trim adhesion ≥3.0N/15mm |
Abrasion Resistance | ≥4.5 on Sutherland Rub Test (100 cycles, 2lb load) |
Barrier Performance | - Oxygen Transmission Rate (OTR): ≤1.2 cm³/m²/day - Moisture Vapor Transmission Rate (MVTR): ≤0.8 g/m²/day |
Temperature Tolerance | - Sealing range: 110–190°C - Storage: -20°C to 45°C |
MOQ | 100 pieces |
Lead Time | Standard: 12–20 days; Custom embossing: 25–35 days |
Sustainability | Recyclable BOPET/PE layers; biodegradable adhesive options (on request) |
Additional Features | - UV-resistant inks (≤5% fading after 500h xenon testing) - Anti-static coating (optional) |
