| Brand Name: | Bright Pack |
| Model Number: | B010 |
| MOQ: | 100pcs |
| Price: | ￥0.02-0.11/pcs |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 200000pcs/day |
| Attribute | Specification |
|---|---|
| Core Safety Mechanism | Push-Twist Lock System (simultaneous push + twist action required; force >5N) |
| Material Composition | Tri-Layer Laminate: PET (12µm) / Al foil (9µm) / LLDPE (50µm) |
| Printing Technology | Minimalist Gravure Printing (≤3 Pantone colors; ΔE≤1.5; FDA 21 CFR §174.5 compliant) |
| Child Resistance | ISO 8316 Compliant (≥85% failure rate in child test group: 42-51 months) |
| Artwork Customization | OEM-Ready Digital Artwork (MOQ 1,000 pcs; EPS/AI vector file support; ≤0.2mm print deviation) |
| Seal Integrity | Tamper-Evident Zipper (leak-proof per ASTM D5486; opening force 4.5-6.0N) |
| Surface Finish | Matte Soft-Touch Coating (abrasion resistance >5,000 cycles) |
| Compliance | ROHS & REACH SVHC (Pb<90ppm, Cd<75ppm), EN 71-3 (migration safety) |
| Parameter | Value/Standard | Test Method/Reference |
|---|---|---|
| Dimensions (W ×H) | Customizable: 80×120 mm to 200×300 mm | ISO 4591 |
| Material Thickness | Total: 71 µm (PET 12µm + Al 9µm + LLDPE 50µm) | ASTM D6988 |
| Print Resolution | 175 LPI (max. 3-color layers) | ISO 12647-2 |
| Lock Activation Force | 5.0 -7.5N (vertical push) + 2.5Nm torque (twist) | ISO 8316 Annex A |
| Child Test Performance | ≥90% failure rate (42-51 month-olds, 25 cycles) | ISO 8316 |
| Seal Strength | ≥4.8 N/15mm (longitudinal seal) | ASTM F88 |
| Water Vapor Transmission | ≤0.5 g/m²/day (38°C, 90% RH) | ASTM E96 |
| Oxygen Barrier | ≤0.8 cc/m²/day (23°C, 0% RH) | ASTM D3985 |
| Operating Temperature | -20 °C to 60°C (no lock mechanism degradation) | ISO 2233 |
| Print Durability | >50 washes (no fading/delamination) | ISO 12947-2 |
| Artwork Setup Time | ≤3 days (digital proofing; CMYK+2 Pantone max) | N/A |
