| Brand Name: | Bright Pack |
| Model Number: | B010 |
| MOQ: | 100pcs |
| Price: | ￥0.02-0.11/pcs |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 200000pcs/day |
| Attribute | Specification |
|---|---|
| Material Composition | PET/CPP laminate or PE-based multilayer structure with anti-static coating |
| Primary Function | ESD protection for automotive USB chargers/cables during storage & transport |
| Key Features | Surface resistivity ≤10⁹Ω, RoHS compliance, moisture barrier, tear notch |
| ESD Protection Mechanism | Static-dissipative layer + conductive grid design (IEC 61340-5-1 compliant) |
| Compatibility | USB-A/C connectors, QC3.0/PD fast-chargers (≤80mm width), cables (Ø≤8mm) |
| Environmental Compliance | RoHS-certified (Heavy metals <0.01ppm), REACH SVHC-free |
| Packaging Options | Customizable sizes (LxW): 50x35mm to 140x145mm; OEM printing |
| Parameter | Value/Standard |
|---|---|
| Surface Resistivity | ≤10⁹ Ω/sq (ASTM D257 or IEC 60093) |
| RoHS Compliance | Certified (Directive 2011/65/EU) |
| Material Thickness | 0.08-0.12 mm |
| Bag Dimensions (LxW) | 60x45mm (std.), customizable up to 190x205mm |
| Sealing Method | Heat-sealed seams + ultrasonic edge reinforcement |
| Temperature Range | -40°C to +80°C |
| Degradation Rate | Non-degradable (standard) / Optional marine-degradable PLA/PBAT blend |
| Shelf Life | 24 months (dry storage) |
| ESD Standards Compliance | IEC 61340-5-1, ANSI/ESD S541 |
| Printing Options | 10-color CMYK/Pantone, holographic security labels |
