| Brand Name: | Bright Pack |
| Model Number: | B010 |
| MOQ: | 100pcs |
| Price: | ￥0.02-0.11/pcs |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 200000pcs/day |
| Attribute Category | Technical Details |
|---|---|
| Material Composition | 3-Layer Barrier Structure: PET (12μm, UV-blocking) / VMPET (9μm, metallized) / PE (50μm, food-grade sealant layer) |
| Barrier Performance | OTR ≤0.05 cc/m²/day (23°C, 50% RH); WVTR ≤0.8 g/m²/day (38°C, 90% RH); UV Blocking >99% (200-400 nm) |
| Printing & Customization | 10-Color Gravure Printing (Pantone-matched), Custom Shapes (hearts, animals, etc.), Finishes: Gloss/Matte Lamination, Spot UV |
| Functional Design | Self-Adhesive Seal (PE layer, peel strength >3N/25mm); Optional Zipper/Childproof Closure; Tear Notch (precision laser-cut) |
| Compliance & Safety | FDA 21 CFR 177.1520, EU 10/2011 (heavy metals <0.01 ppm); BPA-Free; Recyclable (PE layer, LDPE stream) |
| Parameter | Value/Range | Test Standard |
|---|---|---|
| Physical Dimensions | ||
| Thickness | 70-120 μm (standard), up to 250 μm (custom) | ISO 534 |
| Bag Width/Height | 50-300 mm (±0.5mm tolerance) | Custom die-cut tooling |
| Seal Width | ≥5 mm | ASTM F88 |
| Barrier Properties | ||
| Oxygen Transmission (OTR) | ≤0.05 cc/m²/day | ASTM D3985 |
| Water Vapor (WVTR) | ≤0.8 g/m²/day | ASTM F1249 |
| Light Blocking | >99% (UV-Vis spectrum) | ISO 13468 |
| Mechanical Strength | ||
| Seal Strength | ≥25 N/15mm (PE sealant) | ASTM F88 |
| Puncture Resistance | >15N (needle puncture) | ASTM D5748 |
| Elongation at Break | ≥120% (MD), ≥100% (TD) | ISO 527-3 |
| Printing & Customization | ||
| Color Support | 10-color gravure, Pantone library | GRACoL 2013 |
| Artwork Resolution | 300 LPI (line screen), min. 0.1mm font size | ISO 12647-2 |
| Lead Time for Custom Art | 7 days (proof), 15 days (production) | - |
| Production Parameters | ||
| MOQ | 10,000 pcs (custom prints) | - |
| Filling Speed Compatibility | ≤120 bags/min (VFFS machines) | - |
| Certifications | ISO 22000, BRCGS Packaging | - |
