Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
  • Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
  • Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
  • Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
  • Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
  • Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C
Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C

Multi-Layer Al / PE Composite Film Roll Puncture ≥35N Heat Sealable 140–200°C

Place of Origin Guangdong,China
Brand Name Bright Pack
Certification patent for invention、BRC、GRS
Model Number B010
Product Details
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Highlight:

Multi-Layer Al PE Composite Film Roll

,

Transparent Al PE Composite Film Roll

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
$3-3.5/kg
Packaging Details
Export special carton packaging and plate
Delivery Time
11-13work days
Payment Terms
T/T,Western Union
Supply Ability
200000pcs/day
Product Description

Product Attributes & Specifications​

​Category​ ​Attribute​ ​Specification​ ​Test Standard/Notes​
​Material Structure​ Layer Composition PET (Outer) + Aluminum Foil (Barrier) + PE (Sealing) 3–5 layers; customizable
4
5

Thickness Range ​Total: 19–200 μm
​Aluminum: 6–50 μm
​PE: 3–100 μm		 Adjustable per application
4
​Mechanical Properties​ Puncture Resistance ​**≥35 N**​ (Sharp Needle Test) ASTM D7513/D6241
4
13

Tensile Strength (MD/TD) 15–30 MPa Industry standard for packaging films

Elongation at Break 400–600% Ensures flexibility during use
2
​Thermal Performance​ Heat Sealing Range ​140–200°C​ Compatible with PP/PE substrates
5
8

Temperature Resistance ​​-40°C to 120°C​ Suitable for storage/transport
4
13

Thermal Insulation Up to 34.6% efficiency (with 8 wt.% Al content) Enhanced by aluminum layer
1
​Barrier Properties​ Water Vapor Transmission ​​≤0.5 g/m²/day​ ASTM E96
4
13

Oxygen Transmission ​​≤5 cm³/m²/day​ ASTM D3985
4
13
​Optical & Surface​ Surface Finish Glossy/Matt, Silver; Customizable colors/prints Up to 10 printing colors
4

Adhesive Layer Hot-melt or pressure-sensitive adhesive Bonds layers securely
5
​Functional Features​ Seal Integrity Peelable or permanent seals Customizable for easy-open/lidding
8

Applications Pallet covers, machinery packaging, thermal insulation facing, food/dairy lids
4
8
​Roll Specifications​ Max Roll Width ​2.1 m​
4

Max Roll Length ​6,000 m​
4

Core Diameter 76 mm / 152 mm (standard); Customizable
