​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
  • ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm

​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm

Place of Origin Guangdong,China
Brand Name Bright Pack
Certification patent for invention、BRC、GRS
Model Number B010
Product Details
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Highlight:

UV Resistance Transparent Composite Film

,

Customizable Thickness Transparent Composite Film

,

Multi-Layer Transparent Composite Film

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
$3-3.5/kg
Packaging Details
Export special carton packaging and plate
Delivery Time
11-13work days
Payment Terms
T/T,Western Union
Supply Ability
200000pcs/day
Product Description
Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm
Product Attributes
Attribute Description Reference
Material Composition Multi-layer coextruded structure (e.g., PET/PE/PA, PET/EVA, or PA/EVOH/PE) with UV-absorbing/reflective additives (e.g., benzotriazole derivatives, inorganic nanoparticles). 6 7 8
UV Resistance Blocks >99% of UV radiation (300-400 nm); maintains optical/mechanical properties after 2,000+ hours of UV exposure. Additives include red-shifted UVA (e.g., CGL-0139) for long-wave UV blocking. 6 7 8
Optical Properties
  • Transmittance: >90% (visible light, 380 -780 nm)
  • Haze: <5%
  • Gloss: ≥85% (60° angle)
 3 8
Barrier Properties
  • OTR: ≤5 cm³/m²*day (23°C, 0% RH)
  • WVTR: ≤2 g/m²*day (38°C, 90% RH)
 2 3
Mechanical Strength
  • Tensile Strength: ≥120 MPa (MD), ≥100 MPa (TD)
  • Elongation at Break: ≥80%
  • Puncture Resistance: ≥25 N
 2 10
Thermal Stability Withstands -40 °C to 180°C; suitable for retorting (121°C sterilization) and freezing. 3 10
Safety & Compliance Complies with FDA 21 CFR, EU 10/2011, RoHS, and REACH for food/medical contact. 7 8
Processing Features
  • Heat Sealability: 120-180°C (compatible with VFFS/HFFS machines)
  • Printability: Corona-treated surface for high-resolution flexo/gravure printing
 6 10
Product Specifications
Parameter Specification Reference
Thickness 50-200 μm (customizable; tolerance ±5 μm); UV-blocking layer: 0.5-5 μm 6 10
Width 200-1,500 mm (extendable to 3,000 mm for industrial rolls) 10
Roll Dimensions
  • Core Size: 3" (76 mm) or 6" (152 mm)
  • Max. Roll Weight: 150 kg
 10
Physical Properties
  • Density: 1.2-1.4 g/cm³
  • Shrinkage: ≤1.5% (100°C, 30 min)
  • Surface Energy: ≥38 dyne/cm
 3 10
UV Resistance Metrics
  • UV Blocking Efficiency: >99% (300-400 nm)
  • Accelerated Weathering Life: 2-5 years (ISO 4892)
 6 7
Functional Additives Optional: Anti-fog (contact angle <10°), anti-static (surface resistivity ≤10¹¹ Ω/sq), or EMI shielding (transparency >50%, SE ~40 dB) 2 8
Sustainability
  • Recyclability: Mono-material PE/PP variants for single-stream recycling
  • Biodegradable Options: PLA/PHA-based composites (ASTM D6400)
 3 8
Supply Parameters
  • MOQ: 500 kg
  • Lead Time: 15-30 days
  • Packaging: Moisture-proof EPE-foamed cartons
Product Images
​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 0 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 1 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 2 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 3 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 4 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 5 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 6 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 7 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 8 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 9 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 10 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 11 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 12 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 13 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 14 ​Multi-Layer Transparent Composite Film UV Resistance Customizable Thickness 50-200μm 15
