Aluminum Foil Roll Film
>
|
|
| Place of Origin | Guangdong,China |
| Brand Name | Bright Pack |
| Certification | patent for invention、BRC、GRS |
| Model Number | B010 |
| Attribute | Description | Reference |
|---|---|---|
| Material Structure | Multi-layer laminate: PET (outer) + Aluminum Foil (barrier) + PE (inner sealant layer) | 1 5 |
| FDA Compliance | Meets FDA 21 CFR standards for direct food contact and safety | 1 5 8 |
| Barrier Properties | - Oxygen Transmission Rate (OTR): ≤0.05-0.1 cm³/m²/day - Water Vapor Transmission Rate (WVTR): ≤0.02-0.1 g/m²/day |
1 5 |
| Heat Sealability | Heat-sealable inner PE layer; seal strength: 5-12 N/15mm | 1 5 |
| Temperature Resistance | Storage: -30°C to +70°C; Sealing temp: 130°C-200°C | 1 5 |
| Printing Compatibility | Supports up to 8-10-color flexographic/rotogravure printing; Pantone-matched (±ΔE ≤1.5) | 1 5 7 |
| Sustainability | Recyclable PET/Aluminum components; optional eco-friendly PE variants | 1 5 |
| Parameter | Details | Reference |
|---|---|---|
| Thickness | 70-150 μm (customizable) | 1 5 |
| Roll Dimensions | Width: 150-1000 mm Length: 500-3000 meters Core size: 3" or 6" (customizable) |
1 5 |
| Printing Resolution | ≥300 DPI; scratch-resistant coating | 5 7 |
| Packaging Format | Dust-free rolls (cored/core-less); anti-static treatment available | 1 5 |
| Certifications | FDA 21 CFR, EU 10/2011, ISO 22000, LFGB, REACH, RoHS | 1 5 8 |
| MOQ | Standard: 2,000-5,000 units; Full customization: 10,000-20,000 units | 1 5 |
| Add-Ons | Custom logos, QR codes, anti-static layers, micro-perforations |
