Attribute	Specification
Material Composition	Mono-material PE structure with high-barrier MDOPE (Machine Direction Oriented PE) technology. Optional EVOH layer integration for enhanced oxygen resistance (≤0.5 cm³/m²*day OTR).
ClO₂ Compatibility	Anti-corrosion nano-coating on PE surface to prevent ClO₂-induced degradation. Validated for ≤0.1 mg/L ClO₂ migration under accelerated aging (40°C/75% RH for 30 days).
Recyclability	100% recyclable PE structure compliant with EU Single-Use Plastics (SUP) Directive. GRS-certified with ≥20% post-consumer recycled content.
Barrier Properties	- Moisture Vapor Transmission Rate (MVTR): ≤0.5 g/m²day (ASTM E96) - Oxygen Transmission Rate (OTR): ≤1.2 cm³/m²day (ASTM D3985)
Mechanical Performance	- Puncture resistance: ≥2.5 J/mm - Heat-seal strength: ≥3.5 N/15mm (120-150°C) - Cold resistance: -30°C to 50°C
Sustainability Certifications	- TUV OK Compost HOME (optional) - EU Ecolabel - ISO 14001 (environmental management)
MOQ & Logistics	- MOQ: 3,000 rolls (standard), 5,000 rolls (custom designs) - Vacuum-sealed with desiccant and palletized (1,200 × 800 × 1,500 mm)

Product Specifications

Parameter	Details
Dimensions	- Width: 100-2,800 mm (±0.5% tolerance) - Thickness: 80-200 μm (adjustable for vertical/horizontal FFS machines)
Layer Configuration	PE base layer (50-70 μm) / MDOPE barrier layer (20-30 μm) / Anti-corrosion coating (5 μm)
Temperature Range	- Storage: -20°C to 50°C - Operating: -10°C to 85°C - Heat-sealing: 120-150°C
Printing Options	Compatible with water-based, low-VOC inks; supports QR codes for traceability (≥300 dpi resolution)
Compliance Testing	- ClO₂ stability: ASTM F1249 - Heavy metals: Pb/Cd ≤5 ppm (EU 10/2011) - Accelerated aging: 85°C/85% RH for 7 days with <5% performance loss
Sustainability Metrics	- Carbon footprint reduction: ≥20% vs. traditional multi-layer films - Recyclability rate: ≥95% (verified via TUV audits)
