High-Humidity Resistant ClO₂ Film MVTR ≤0.5 G/m²·day & Anti-Static Coating

Place of Origin	Guangdong,China
Brand Name	Bright Pack
Certification	patent for invention、BRC、GRS
Model Number	B010

Product Details

Customization:

Support

Colour:

Up To 10 Colour Or No Printed

Odor Proof:

Yes

Custom Order:

YES.

Colors:

CMYK/Pantone

Sample:

Free

Puncture Resistant:

Yes

Packaging Type:

Bulk Pack

Quantity Per Pack:

100

Recyclable:

Yes

Quantity:

Pack Of 100 Bags

Bag Type:

Three Side Seal Stand Up Bag

Bpa Free:

Yes

Color:

Transparent

Height:

115 MM

Highlight:

Recyclable ClO₂ Film

High Humidity Resistant ClO₂ Film

Anti-Static Coating ClO₂ Film

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

$3-3.5/kg

Packaging Details

Export special carton packaging and plate

Delivery Time

11-13work days

Payment Terms

T/T,Western Union

Supply Ability

200000pcs/day

Product Description

High-Humidity Resistant ClO₂ Film MVTR ≤0.5 G/m²·day & Anti-Static Coating

Product Attributes

Attribute	Specification
Material Composition	4-layer co-extruded structure: PET (outer layer)/Adhesive/EVOH (barrier core)/Anti-Static PE (inner layer) with nano-silica reinforcement for enhanced humidity resistance.
Certifications	ISO 22000, MIL-PRF-81705C (anti-static compliance), and FDA 21 CFR 177.1390 (food contact safety).
Barrier Performance	Moisture vapor transmission rate (MVTR): ≤0.5 g/m²day (ASTM E96) Oxygen transmission rate (OTR): ≤1.2 cm³/m²day (ASTM D3985)
Anti-Static Properties	Surface resistivity: 10⁹ -10¹² Ω/sq (ISO 1853) Static decay: <2 seconds (from ±5,000 V to ±50 V)
Humidity Resistance	Maintains performance at 85% RH and 40-85°C, validated by 7-day accelerated aging tests.
Mechanical Strength	Puncture resistance: ≥2.5 J/mm Heat-seal strength: ≥3.5 N/15mm (sealing temp: 120-150°C)
Customization	Width: 100-2,800 mm (±0.5% tolerance) Thickness: 80-200 μm Optional QR code pre-printing (low-VOC inks)
Sustainability	Recyclable PE layer (mono-material design); GRS-certified recycled PET available (≥15% post-consumer content).

Product Specifications

Parameter	Details
Dimensions	Roll width: 100-2,800 mm Roll length: 500-5,000 m (core ID: 3"/76 mm)
Layer Configuration	PET (20-30 μm) / Adhesive (5 μm) / EVOH (8-12 μm) / Anti-static PE (40-60 μm)
Temperature Range	Storage: -20°C to 50°C Operating: -10°C to 85°C Heat-sealing: 120-150°C
Anti-Static Coating	Surface resistance: ≤1×10¹¹ Ω/sq (ASTM D257) Volume resistance: ≤1×10¹⁰ Ω*cm (MIL-PRF-81705C)
Packaging & MOQ	MOQ: 3,000 rolls (standard design) Vacuum-sealed with desiccant, palletized with moisture-proof wrapping
Compliance Testing	Heavy metals (Pb/Cd ≤5 ppm, EU 10/2011) ClO₂ gas permeability (ASTM F1249) Accelerated aging (85°C/85% RH for 7 days)
