Aluminum Foil Roll Film
>
High-Barrier Flaxseed Protein Energy Bar Composite Film ≤0.5 Cm³/m²·day OTR & BRCGS/ISO 22000 Certified

High-Barrier Flaxseed Protein Energy Bar Composite Film ≤0.5 Cm³/m²·day OTR & BRCGS/ISO 22000 Certified

Brand Name: Bright Pack
Model Number: B010
MOQ: 100pcs
Price: 0.03-0.1usd/pc
Payment Terms: T/T,Western Union
Supply Ability: 200000pcs/day
Detail Information
Place of Origin:
Guangdong,China
Certification:
patent for invention、BRC、GRS
Customization:
Support
Colour:
Up To 10 Colour Or No Printed
Odor Proof:
Yes
Custom Order:
YES.
Colors:
CMYK/Pantone
Sample:
Free
Puncture Resistant:
Yes
Packaging Type:
Bulk Pack
Quantity Per Pack:
100
Recyclable:
Yes
Quantity:
Pack Of 100 Bags
Bag Type:
Three Side Seal Stand Up Bag
Bpa Free:
Yes
Color:
Transparent
Height:
115 MM
Packaging Details:
Export special carton packaging and plate
Supply Ability:
200000pcs/day
Highlight:

Flaxseed Protein Energy Bar Composite Film

,

High Barrier Energy Bar Composite Film

Product Description
High-Barrier Flaxseed Protein Energy Bar Composite Film ≤0.5 Cm³/m²·day OTR & BRCGS/ISO 22000 Certified
Product Attributes
Attribute Specification
Material Composition 5-layer co-extruded structure: PET (outer layer)/Adhesive/EVOH/Adhesive/PE (sealant layer) with optional metallized aluminum coating for enhanced UV/oxygen resistance.
Certifications BRCGS Packaging Grade AA+ (2025 edition), ISO 22000, FDA 21 CFR 177.1390 (food contact), and Halal/Kosher (optional).
Barrier Performance
  • Oxygen transmission rate (OTR): ≤0.5 cm³/m²*day*atm (ASTM D3985)
  • Moisture vapor transmission rate (MVTR): ≤1.0 g/m²*day (ASTM E96)
Mechanical Properties
  • Puncture resistance: ≥2.8 J/mm
  • Heat-seal strength: ≥3.8 N/15mm (100-140°C)
  • Cold resistance: -30°C to 50°C
Customization
  • Width: 100 -2,800 mm
  • Thickness: 60 -200 μm
  • Pre-printed QR codes/Pantone-matched designs (low-VOC inks)
Sustainability Recyclable PE layer (mono-material design); GRS-certified recycled PET/PE available (≥20% post-consumer content).
Product Specifications
Parameter Details
Dimensions
  • Roll width: 100 -2,800 mm (±0.5% tolerance)
  • Roll length: 300 -5,000 m per roll
Layer Configuration PET (15-25 μm) / Adhesive (3-5 μm) / EVOH (6-10 μm) / Adhesive (3-5 μm) / PE sealant (30-50 μm)
Temperature Range
  • Storage: -30°C to 50°C
  • Heat-sealing: 100 -140°C
  • Retort compatibility: Non-retort grade
Printing & Coating 6-8 color flexographic printing with FDA-compliant inks; optional anti-static coating (surface resistivity 10⁹-10¹² Ω/sq)
MOQ & Packaging
  • MOQ: 3,000 rolls (standard), 5,000 rolls (custom designs)
  • Vacuum-sealed on 3" cores, palletized with moisture-proof wrapping
Compliance Testing Third-party tested for OTR, MVTR, heavy metals (Pb/Cd ≤5 ppm), and migration safety (EU 10/2011)
