| Brand Name: | Bright Pack |
| Model Number: | B010 |
| MOQ: | 100pcs |
| Price: | $3-3.5/kg |
| Packaging Details: | Export special carton packaging and plate |
| Payment Terms: | T/T,Western Union |
| Attribute | Specification |
|---|---|
| Material Composition | 7-11 layer co-extruded structure (PET/EVOH/PE or PET/AL/PE combinations) with EVOH oxygen barrier layer. Optional metallized aluminum layer for enhanced UV/oxygen resistance. |
| Certifications | FDA 21 CFR 177.1520 (food contact), BRCGS Grade AA+ (highest food safety rating), ISO 22000, Halal/Kosher (on request). |
| Barrier Performance | - Oxygen transmission rate (OTR): ≤0.5 cm³/m²*day*atm (ASTM D3985) - Moisture vapor transmission rate (MVTR): ≤0.5 g/m²/day (ASTM E96) |
| Retort-Safe Properties | Withstands high-temperature sterilization up to 121°C (250°F) for 30 minutes, compatible with retort processing. |
| Anti-Static Coating | Surface resistivity 10⁹ -10¹² Ω/sq (ESD-safe for powder filling). |
| Customization | Adjustable roll width (100 -2,800 mm), thickness (70 -250 µm), and pre-printed FNSKU/QR codes. |
| Seal Integrity | Heat-seal strength ≥5 N/15mm (120-160°C), puncture resistance ≥3.5 J/mm. |
| Sustainability | Recyclable mono-material PE layer or GRS-certified recycled PET (20% post-consumer content). |
| Parameter | Details |
|---|---|
| Dimensions | - Roll width: 100 -2,800 mm (customizable) - Roll length: 500 -5,000 m per roll. |
| Thickness | Total: 70 -250 µm (e.g., PET 12-25 µm + EVOH 6-9 µm + PE 50-100 µm). |
| Barrier Layer | EVOH (6-9 µm) or metallized aluminum (20-30 nm) for OTR ≤0.5 cm³/m²*day. |
| Temperature Resistance | - Storage: -40°C to 50°C - Retort sterilization: ≤121°C. |
| Printing & Design | 8-10 color flexographic printing with FDA-compliant, low-VOC inks; supports Pantone color matching. |
| MOQ & Packaging | - MOQ: 5,000 rolls (standard design), 10,000 rolls (custom designs) - Vacuum-sealed on 3" or 6" cores, palletized with FSC-certified boxes. |
| Compliance Testing | Third-party tested for OTR, MVTR, heavy metals (Pb/Cd ≤10 ppm), and migration safety. |
