Material Composition	Multi-layer composite: Aluminum Foil (AL) for ultra-barrier protection and Polyethylene (PE) for flexibility and heat-sealability. Optimized for heavy-duty applications such as industrial packaging and structural reinforcement.
Cost Efficiency	40% cost reduction achieved through material optimization (reduced waste in production) and logistics efficiency (compact roll dimensions: 1.23m width × 3000m length).
Customization Service	24-hour rapid design support for tailored dimensions (width: 520-1020mm), thickness (0.08-0.20mm), and printing patterns (digital/flexographic).
Durability	Enhanced tensile strength (MD: ≥220 MPa, TD: ≥180 MPa) and puncture resistance (≥8 N) due to AL/PE synergy, suitable for abrasive environments.
Applications	Ideal for heavy-duty packaging (construction materials, automotive parts), moisture barriers, and industrial liner systems.

Technical Specifications

Layer Thickness	AL: 6-12μm
Mechanical Properties	Tensile Strength (MD/TD): ≥220/180 MPa (ASTM D882) Elongation at Break: ≥500% (ASTM D882)
Barrier Performance	Oxygen Transmission Rate (OTR): ≤0.5 cc/m²/day Water Vapor Transmission Rate (WVTR): ≤0.3 g/m²/day
Thermal Stability	Operating Temperature: -50°C to 120°C; compatible with heat-sealing (120-160°C) and freezing.
Roll Dimensions	Standard: 1.23m (width) × 3000m (length)
Certifications	Complies with FDA 21 CFR 177.1390 (food-grade safety) and ISO 14001 (environmental management).
Printing Compatibility	PE surface treated (≥38 dyne/cm) for high-resolution printing; supports CMYK/Pantone color matching.
Sustainability	PE layer contains 20-30% recycled content (optional); AL layer recyclable via dedicated streams.
